IACS Approved Marine Studless Open Link AM1, AM2, AM3 Stainless Steel Anchor Chain

Product Categories
CHONGQING GOHI MARINE EQUIPMENT CO., LTD.
Contact Now

IACS Approved Marine Studless Open Link AM1, AM2, AM3 Stainless Steel Anchor Chain

  • 1
  • 2

Brand Name : GH

Model Number : Anchor Chain

Certification : CCS, BV, ABS, DNV-GL, RMRS, LR, RINA

Place of Origin : CHINA

MOQ : 1 Knots

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 6000 Knots Per Month

Delivery Time : 5-30 Days

Packaging Details : Naked

Material : AM1:Q235 AM2:CM490 AM3:CM690

Surface treatment : primary color, black paint

Contact Now

The studless open link anchor chains are approved by CCS, BV, ABS, DNV-GL, LR, NK, KR, RMRS, IRS etc.

It can be black paint and galvanized according to the client's requirement.

Chain diameter/mm Link size/mm BM1 BM2 BM3 Chain diameter/mm Link size/mm BM1 BM2 BM3
DФ Outer length L × outer width B Breaking load/KN Breaking load/KN Breaking load/KN Outer length L × outer width W Breaking load/KN Breaking load/KN Breaking load/KN
12.5 75×45 57.81 82.6 112.8 42 252×151.2 652.68 915.3 1273.6
14 84×50.4 69.93 101.9 141.51 44 264×158.4 716.32 999.6 1398
16 96×57.4 94.72 132.3 184.83 46 276×165.6 782.92 1097.6 1527.8
17.5 105×63 113.31 157.78 221.1 48 288×172.8 852.48 1195.6 1663.5
19 114×68.4 133.57 187.2 260.64 50 300×180 926.09 1293.6 1805
20.5 123×73.8 155.49 217.27 303.42 52 312×187.2 1000.48 1395.26 1952.28
22 132×79.2 179.08 250.9 349.4 54 324×194.4 1078.92 1504.66 2105.36
24 144×86.4 213.25 298.9 415.8 56 336×201.6 1160.32 1618.18 2264.2
26 156×93.6 250.12 350.8 488 58 348×208.8 1244.68 1735.82 2428.8
28 168×100.8 290.08 406.7 566 60 360×216 1332 1857.6 2599.2
30 180×108 333 467.5 649.8 62 372×223.2 1422.28 1983.5 2775.36
32 192×115.2 378.88 531.2 739.3 64 384×230.4 1515.52 2113.54 2957.32
34 204×122.4 427.72 599.8 834.6 66 396×237.6 1611.72 2247.7 3145.04
36 216×129.6 479.52 672.3 935.7 68 408×244.8 1710.88 2385.98 3338.52
38 228×136.8 534.28 748.7 1042.5 70 420×252 1813 2528.4 3537.8
40 240×144 592 829.1 1155.2

IACS Approved Marine Studless Open Link AM1, AM2, AM3 Stainless Steel Anchor ChainIACS Approved Marine Studless Open Link AM1, AM2, AM3 Stainless Steel Anchor ChainIACS Approved Marine Studless Open Link AM1, AM2, AM3 Stainless Steel Anchor Chain


China IACS Approved Marine Studless Open Link AM1, AM2, AM3 Stainless Steel Anchor Chain wholesale

IACS Approved Marine Studless Open Link AM1, AM2, AM3 Stainless Steel Anchor Chain Images
